Re: 72' CB350 - First build.
« Reply #30 on: Dec 16, 2010, 12:25:07 »
Nice work Danish. Gonna be a sweet lil rocket!

1972 CB500 Rising Sun
1972 CB500  Goldmember
1972 CL100 Scrambler
1972 CB500 hybrid streetfighter,Project "Barely Legal"
Tassels are for Titties and Kiddies

Offline jeff4uk

  • Posts: 369
    • 71 triumph T100c
Re: 72' CB350 - First build.
« Reply #31 on: Dec 17, 2010, 14:04:37 »
Nice work man really enjoying this thread hope this helps to
The longer bend  gose from the inside out

lace all the wheel then lay it flat

start with an inside out spocke then count 5 to the right cross this one under the other and tapeit in place

go all the way round both sides

where the brake disc gose i put  20mm wood blocks to raise the rim inline with the spockes

this methared was used on my caferacer with borrani rims

hope the helped and not nindered!!!!

Offline Danish_Cafe

  • Posts: 77
Re: 72' CB350 - First build.
« Reply #32 on: Dec 18, 2010, 09:51:39 »
Jeff, u are the man! That's just perfect for me, can't go wrong now!

Thanks alot.
I will post pictures when i get to do some work on the wheels, waiting on spokes as we speak.

Offline Danish_Cafe

  • Posts: 77
Re: 72' CB350 - First build.
« Reply #33 on: Dec 23, 2010, 11:13:44 »
Not the biggest progress, but got these in the mail today, new rubber sealed bearings for front and rear wheel, and now only need the spokes to finish my wheels:

Also i'm waiting for the weather to clear up, so i can pick up my new frame. Can't go anywhere by car due to snow and ice  :-\
« Last Edit: Dec 23, 2010, 11:37:02 by Danish_Cafe »

Offline Danish_Cafe

  • Posts: 77
72' CB350 - First build. ( Frame 0 - Grinder 1 )
« Reply #34 on: Jan 05, 2011, 08:25:48 »
Finally picked up the new frame this weekend. Cut off the brackets etc. that i don't need and now it's ready to be cleaned and paintet:

Also fitted the new wheelbearings, front and rear:

And did the small job of finishing the brake plates, so now hubs and rims are ready for spokes:

Update will follow when frame is paintet  ;D
« Last Edit: Jan 05, 2011, 09:20:51 by Danish_Cafe »

Offline diesel450

  • *
  • Posts: 2450
  • "Fast with a past"
Re: 72' CB350 - First build.
« Reply #35 on: Jan 05, 2011, 10:21:31 »
Did you paint or powder the rims? if paint what did you use? I worry about getting the tires onto painted rims without chipping them all to hell and back.

Offline Danish_Cafe

  • Posts: 77
Re: 72' CB350 - First build.
« Reply #36 on: Jan 05, 2011, 14:35:48 »
The rims are just spraypaintet. 2 coats of primer and 3 coats of black. I had the exact same worries about the paint chipping when fitting tires, but i seems to hold reasonable good. I've hit some parts with a rubber hammer really hard a few times and the paint didn't chip. I thinks if you use a lot of lubricant when fitting they tires it will be alright.

Offline Danish_Cafe

  • Posts: 77
72' CB350 - Sailors Grave!
« Reply #37 on: Jan 06, 2011, 14:43:45 »
Finally it feels like i'm moving forward. Frame blasted and primed, will lay some color tomorrow and then on to assembly.

Also named the bike "sailors Grave" since i spend half the year at sea and spend my money on the bike when i'm home.  :D

Offline cafematty

  • *
  • Posts: 635
  • Alcohol disposal unit.
    • CafeMatty
Re: 72' CB350 - First build.
« Reply #38 on: Jan 06, 2011, 15:20:40 »
Dude, this build is redic! NFJ on that engine! Can't wait to see this come together...
81 BMW R65

"You're asking these questions on a forum where the sawzalls get more use than the credit cards..."

Offline kookie31

  • Posts: 207
  • i built it, therefore its mine...
Re: 72' CB350 - First build.
« Reply #39 on: Jan 06, 2011, 15:46:09 »
Man this build is almost making me want to take mine all apart and do it all over again (wife would kill me lol). Real nice work! Can't wait to see this come together. I'm real interested in how the rear seat is going to come out. It all looks great, man! Congrats on the lil one, as well! I have a three month old and I just sit him in my lap and scroll through pics and videos of this stuff. START 'EM YOUNG!!
