An Atlas Craftsman 6" Lathe Non Restoration

The next job is a reversing switch. ChinaBay doesn't thrill me. Furnas (the original part)eludes me. The cost of the stock Clausing part depresses me. It will probably be Dayton by way of Hobson's choice.

I'm also on the lookout for a steady and follow rest. I'm not looking for a hand out but refuse to pay inflated EvilBay prices. I'm always on the lookout for original 1" -10 TPI chucks, 3 & 4 jaw.

Any curious MT2 (headstock) or MT1 (tailstock) tooling is also on the list.

The want list for the mill is extensive and I'll detail that elswhere.

I'm already looking ahead. The follow on to the 6" lathe you see here is either a DSM 59 Hardinge or it's bigger brother the HLV-H. An alternative to the DSM is the nearly direct copy the Feeler.
These are referred to as "second operation lathes". The machines provide the tooling and CNC programmed meat operates them.
The point is I don't have the room for a CNC turning or milling center and honestly couldn't keep one busy. In fact I probably couldn't keep an old Brown & Sharpe auto screw machine busy.
I don't see runs of much more than several hundred in my future.

The one job that may turn into a 3 shift 24/7 nightmare will be a slow ramp up and will eventually have to compete for market share anyway. I hesitate to elaborate mainly because I don't want to bore anyone more than I already have. The other reason is it's a job so far removed from motorcycles that it really doesn't belong here.
Initial testing showed promise. Quality control was an issue due to using less than ideal equipment. Materials were an issue because some suppliers think that copper is copper, aluminum is aluminum and steel is steel. I'm fortunate that the experience gained was at least worth the weight of the scrap I made.

I should have the first test bar on the lathe this week.

Okay , buckle up , short sharp rant.
So in no particular order I have
purchased and shipped a lathe 1/3 of the way across the country
I have struggled with the deterioration due to years of neglect.
I have exorcised the wanton destruction of flying monkeys with hammers.
I sourced obsolete and discontinued parts from the likes of mymachineshop.net and littlemachineshop.com
Someone left the side door open at practical machinist and was able to post WTB .
An ebay seller I've known for years says "does this look familiar?" and I had new half nuts.
Clausing. If you ever speak with Brian or Tom about old inventory thank them for being there.
Help has arrived in the form of anonymous packages containing everything from HSS to bearings, to random pieces of stock. I'll just say Thank You and quit wondering who you are :)
I have limited tools
I'm starting over, at 65. with an eons old 6" metal lathe.
And all this one facebook keyboard warrior can say is
"I was taught to never place anything on the ways"
Then proceeds to school me on care and feeding of machinery in general, lathes specifically and my lathe in particular.


The reply went like this.
It's not your lathe. It's my lathe.
If it were your lathe you could happily restore it to museum quality non functional beauty.
I intend to use the hell out of this lathe once it's functional and quite possibly never pretty.
If your intent is to demean, denigrate, deride and "mansplain" care and feeding of a lathe to a retired millwright then have at it , somewhere else, to someone else, some other time.


The technical division of the mad Irish army made the next week of internet connectivity exceedingly difficult for this mutt. I have some very interesting family and friends.


Look , I have never, ever, demeaned or derided anyone's work. If I can't stand to look at it I just don't.
I can see potential beauty where someone else sees scrap.
I possibly didn't respond well to criticism in this case.
I didn't enjoy being taken to school by a 30 something keyboard warrior.

But he's right.

Good shop practices are good shop practices, then, now, and always.
If he had stopped there without a near copy and paste from NavPubDoc, MM & MR 3-2 intro to machine practices I wouldn't be typing this wall of text.


In conclusion, don't leave ANYTHING on the ways or gawd almighty will kill a kitten.
And the next time you're confronted by some invasive species of keyboard warrior, let it go. Your time is far better spent working on or with your machines.
:EOR

Okay , it runs. but wait there's more.
@gggGary , thanks for part of the solution.
The belt is crap or has a couple of flat spots on it. Back off the tension so far you can't put a tool into aluminum and it runs fine. give it any tension at all and it's a bucking bronco.
Interlude for some good news. The time I spent on the gears paid off. There was so much crud in the root that there was no way to get close to a mesh. Razor blade, caustic chemicals, miniature files, multiple teeth breech, wash, rinse, repeat.
The gear train is nearly silent.
More good news. No detectable axial or radial slop, none, and very little heating.
Okay back to the flying monkeys with hammers.
The spindle may have near zero detectable run out between the bearing surfaces but the register for the chuck is messed up. Not only that the 2MT taper in the spindle is corroded.
A super sharp piece of 5% cobalt HSS reestablished the face but there is little that can be done for the 1.375 outer diameter. Neither of the chucks I have make use of the specified 1.000" dia register so I have to make do with the face . I'll include the pdf.
It appears I have a ways to go before I have a tool I can use. For those of you that might suggest...
No, I could turn between centers right now if I took the taper out but that gets old real fast.
I'll suss out the damaged 2MT in the spindle bore this weekend. The reamers are on the way.
Then I have to decide which center to go with, the register (and which chuck, 4 jaw , duh) or the spindle ID .
it's 11:45 pip emma out here on the left coast. I've done enough damage for one day.
Now where was the flying monkey repellent ?


Attachments

  • death-mob-wizard-of-oz.gif
    2.6 MB · Views: 171
  • Nearly_running.jpeg
    866.2 KB · Views: 150
  • 701-083.PDF
    276 KB · Views: 137
The reamer set I received from the AmaZombies. looks good.
I tied the roughing an finish back to back with each other and , parallel.
I did the same with a known good 2MT taper and, parallel.
So far so good.
Now to dial the face register and the 2MT taper and record the run out. The face should be zero after a skim of the face. The 2MT taper will have to be cleaned up prior to indicating.
Then the options.
Move the 2MT taper. This is actually the easiest as the reamers both have a rear center.
Simply offset a center held in the tool holder or offset the tail stock the amount of radial run out , lock the spindle and advance the reamer.
Move the face. This sucks as anything done to the face other than perfectly perpendicular to the axis is just brain dead and would work only with that specific accessory.
Face to face chucks. Where you install a chuck on the spindle and true a shaft to it no mater what else is going on.
Place the other chuck on the shaft with its jaws facing the installed chuck.
Reproduce its angular misalignment on the shaft and verify by indicating on it's register.
if the misalignment between the OD of the chuck, the registration face and to a lesser degree, the "natural" center in the case of the scroll chuck agree, The spindle is bent.
If the register does not agree with the OD or the "natural" center in a scroll chuck but the "natural" center do agree then straighten the register. (what a bunch of words)
The four jaw is easier once the three jaw is close. Get the run out and angular distortion out of the shaft. resort to the cigarette paper trick for out of round, tap to center for the live end.
Install the 4 jaw on the shaft exposing the register. True up the OD for run out. indicate the register. True up the register if necessary.
Wash , rinse , repeat, until this becomes a repeatable operation. If it doesn't , run around in circles (isn't that what we've been doing?) screaming "Murphy!!! WHHHHHHY Me !!!!"
Then it's back to the internal taper and making it agree to the total indicated run out ( hopefully near nil at this point)
If not then it's easy enough to move the taper a "few" thousands.
and so it goes


Attachments

  • Federal_runout.jpeg
    494.1 KB · Views: 157
  • Starret_runout.jpeg
    527.1 KB · Views: 147
Once I counter bored a register in the chuck
The rest was easy, The damage was beyond abrasives and a careful dial in of the register allowed for a .002" skim cut on the diameter and face.

Avery brief vid of the machine reveals the work on the gear train was well worth it. Just imagine inspection of every tooth and root of every gear in inventory. Imagine "blueprinting" of every spacer, bushing and keyed spacer. Imagine spending hours sorting out a banjo bracket that had been attacked by the flying monkeys with hammers. Then it was the lead screw alignment including centering on new half nuts to the point where there was full engagement without deflecting the lead screw and full disengagement.

It was worth the effort.



Attachments

  • chuck_to_chuck.jpeg
    816.8 KB · Views: 142
  • 3jaw_clean.jpeg
    795.2 KB · Views: 177
Last edited:
I'll keep it short. I just had to share a thought.

"lil" John Buttera, "When you make each part, each sub assembly, each assembly, to the very best of you time, tools, talent, and ability, only then will the sum total of the parts be greater than the whole."

For those of you that don't recognize the name, it's worth a deep dive.

For all the deburring every tooth. For all the not accepting anything but perfect alignment. For not accepting good enough. The results are worth it.

As the non restoration title states it's near time for this machine to start earning its keep. Its reward will be an eventual complete restoration because it will be made all the more easier since it will be completely functional.

The previous clip is short but it's not so much the image, it's the sound. This is what happens when there is no compromise, when there is decades of experience applied, when the expected result depends on completing the details.

The result is worth the effort.

Hi Dennis, We turned off services and saved $200 a month.
Spectrum (Charter Communications) are a bunch of greedy robbers.
Had internet, phone and cable back on yesterday so I did a speed test using Spectrum. (after almost six months being stuck in hotels we finally have a date to return home - maybe)
We pay for 100Mb but actually got 29.6Mb download. and 11.2 Mb upload.
I'm really fed up with complaining as it's about the same as when Brighthouse were running things, 20 years and no change.
There is a new company running fiber optic cable though but I can't get an answer from them about ' Taxes & Fee's' so may be a non starter.
I did contact them by e-mail and pointed out all the major towns and cities in Britain had fiber optics by 1996

new tool.
Good to hear from you Peter.
Is the cell phone working?


Attachments

  • turret_1.jpg
    32.8 KB · Views: 91
  • turret_2.jpg
    27.9 KB · Views: 84
  • turret_3.jpg
    28.3 KB · Views: 90
  • turret_4.jpg
    27.1 KB · Views: 88
UPS tried to kill the ball screws. Good packaging saved them.
Waiting on the ball nutz.


Attachments

  • toob_1.jpg
    332.9 KB · Views: 82
  • toob.jpg
    331.4 KB · Views: 90
  • ballscrew.jpg
    662.5 KB · Views: 102
