Finally wheeled the bike out from where I built it, as I'll need more elbow room when it comes to taking it apart. Here it is next to my 93 888 SP4 rep.. The footpegs are missing as need them to make the exhaust brackets. The tank strap has been cut to size and its hook riveted, works ok, but breaks up the lines of the tank to me. Maybe something to change later, in the meantime still lots to do to get it on the road by my self imposed deadline of April.


Attachments

Bevelheadmhr

Member
DTT BOTM WINNER
Made a start machining the new velocity stack, just drilled it to match the size of the S&S carb so far..


With the Ironhead now in my garage, makes it easier to work on. Got the sprockets lined up, they weren't as misaligned as I first thought, so only needed a small spacer behind the front sprocket.

Finally one of the last jobs to do before the bike is taken apart for powder coating is to make the exhaust brackets. These are a bit trickier than usual as they need to be mounted to the frame via two bolts, not just one. This is because they sit almost parallel to the ground, at an acute angle to the silencers so they need to be sturdy. They are made from 10mm alloy plate, they'll sit behind the footpeg mounts (not in front as in the photo), and once drilled and shaped they'll need to be heated and bent to take up the 20mm offset to the silencers..


Attachments

Bevelheadmhr

Member
DTT BOTM WINNER
Couldn't do much this week, waiting on some help to lift the engine out of the frame, so I decided to weigh the bike before it comes apart. I used a couple of bathroom scales under each wheel, then swapped them around to check if there was any difference in readings.. there wasn't.

The bike was weighed without oil or fuel... Front weight = 185lbs, rear = 202lbs total 387lbs

4 litres of oil weighs 3.7kg or 8lbs (I checked), while half a tank of fuel will be around 20lbs... gives 415lbs ready to ride. I was aiming for 420lbs, so happy with that.


Bevelheadmhr

Member
DTT BOTM WINNER
Cuba Libre said:
There's a reason these are called featherbeds... ;D

M.
The name came about when ...Harold Daniell was a successful Isle of Man TT racer with three victories and several placings in the Tourist Trophy races and the Manx Grand Prix. After testing the new Norton frame in 1950 he declared that it was like "riding on a featherbed" compared with riding the "garden gate'' Norton — and it has been called the featherbed frame ever since.

Here's a photo of the LHS.. exhaust mounts all done now..


Attachments

canyoncarver

'hacking is learning'
DTT BOTM WINNER
Hoosier Daddy said:
She's going to be a handful for sure.
Absolutely gorgeous
Let me know when I can nominate her for BOTM... so deserving

Agreed.... Sure to rattle some cages!


coyote13

New Member
::starts slow clap::

I know she isn't finished, but I figure if I start the slow clap now, the crowd will be roaring by the time you're done!


Bevelheadmhr

Member
DTT BOTM WINNER
Photobucket has maxed out again (all the photos will reappear on the 19th), so I'll try using attachments instead..

Found a hardened steel pin that just happened to be the right size to act as the clutch pushrod, which saved some work.. The one off slave cylinder is shown next to the original cable operated ball and ramp clutch actuator.

While my mate Jeff did a great job machining a new velocity stack for me, from solid billet. Just need to slim down the base a few mm (make sure it doesn't block the vent arrowed) and polish it..


Attachments

DrJ

New Member
The Tritoneers are gonna call sacrilege on me for saying the best looking motor for a featherbed frame is the Harley ironhead.


buckeyebike

New Member
Beautiful, just beautiful. The lines are great and although I am not a fan of a Harley, that engine sure looks nice in there. Good job.

I am not sure J, I still like a pair of preunits . . . ;)



Bevelheadmhr

Member
DTT BOTM WINNER
It would've been easier to use a later Evo 883 or 1200 engine, but they didn't look quite right to me, too modern to suite the Norton frame. The Ironhead fills the frame nicely, the old Triumph engines look a little small in a Triton, with too much space around them.

Today made a points cover, I had one made for a Big Twin, but they have the two mounting holes horizontal, while Sportsters have theirs vertical (No idea why). I started out by hacksawing out a raw disc from some scrap 6mm plate, drilled and countersunk two mounting holes, then handed it to Jeff who machined it round in the lathe, added a bevel around the edge and machined the face smooth. I didn't polish it as I want to get it engraved.

To hold it he couldn't drill a centre hole, or hold it in the chuck. I was surprised how it was done. He used two thick alloy discs, both a little smaller than the points cover, pressed tightly either side of the cover. One disc was held in the chuck (the part that spins) and the other was pushed hard against the front of the cover and held by the lathe tailstock. Very clever, I'd never had thought of doing that.


Attachments

DrJ

New Member
Bevelheadmhr said:
It would've been easier to use a later Evo 883 or 1200 engine, but they didn't look quite right to me, too modern to suite the Norton frame.
And the belt drive just wouldn't look right.
