The first step in the rebuild will be to get the engine mechanically sound again. It is burning oil and I suspect the valve guides/seals are failing. I rebuilt the top end about 5 years ago, but it was my first time messing around in an engine so who knows what I did. It has also been popping out of 2nd gear, so I will be rebuilding the bottom end this time too. The last time I rode it, oil was gushing out of it when I got home. Let's see what the problem is.
First take off the pretty stuff.
Then pop the engine out with a rubber mallet.
Let's get to work....
Found the problem. The clutch pushrod oil seal popped out. The new one will get installed with some loctite.
Will Loctite be sufficient to secure the new seal from any increase in crankcase pressure?
I've seen some quite simple oil seal 'retainer' designs which are effective and secure using the fastener which holds down the stator wires.
I think it will be enough. The seal doesn't fit very tightly. The friction of the rod might have actually pulled it out. The crankcase is vented with a sizable tube so pressure buildup should be minimal. If it happens again I will add a retainer as you suggested.
I spent last night taking the top end apart. First I had to remove the ignition. This turned out to be much harder than planned. I have one of PAMCO's original electronic ignitions installed, the one without the electronic advance.
It turns out that all of the movement of the advance mechanism caused the little nubs of the advance weights to deform the aluminum of the timing rotor. It was originally just a straight slot. I have only put MAYBE 2000 miles on this ignition. Looks like you should have used a harder material Pete! Because there is a small lip on the shaft of the advancer, the deformed rotor would not come off. I had to pry it off. You can kind of see where the aluminum scraped on the shaft. I was planning to get a new ignition for it anyway. I don't like all of the exposed electronics of the PAMCO and on this particular model, you can't adjust the two pickups separately.
Once I got that off, I could disassemble the rest.
Uh Oh. see you are WAY more organized than I am. Lemme know if you need any help man, I'm not too far away and hopefully have less on the table in a couple weeks
I've been working out of town this week. I'll be back to wrenching tonight.
In the meantime, while I was disassembling the top end, I also took my carbs apart. I will be taking them to a local shop to get cleaned and they will also get refreshed with some new parts.
Interestingly, I found that the two carbs had different needles in them. Not only is the top different, but they have different profiles. When I bought the bike, it had two different sized jets in each carb, 130 in one and 145 in the other. I put 135s in both, but didn't realize the needles were different. Maybe this is why I could never really get it to run well. I was thinking about just throwing some mikunis on, but I will give these turds one more shot. Hopefully getting the same parts in both carbs will help them run better.
Mike, I have a box with at least 4 pairs of these CB450 carbs. if you need anything just let me know and I'll mail you what you need or the whole box.
I too had the same issue with my carbs, different size main jets on each carb, never stopped to look if both needles were the same or not though.
