400four, Dueling Banjos

ridesolo

You only bear responsibility for your own actions
DTT SUPPORTER
DTT BOTM WINNER
Got 'em! I believe this is what you are looking for, right?



ridesolo

You only bear responsibility for your own actions
DTT SUPPORTER
DTT BOTM WINNER
I'll do it very soon and let you know.


ronnie

Calm down and sail on
Yea bud! Exactly what I need. Would you please open them up and see if the sockets can be saved? I am gonna PM you.
I believe I have a set from a 350f but I cant check them for another two weeks as I'm at work right now.


trek97

No Custom Title
DTT BOTM WINNER
Getting some odds and ends done...












Im not a fan of the large boxy tail light,
swapping the smaller oval from a 69 CB350...










ridesolo

You only bear responsibility for your own actions
DTT SUPPORTER
DTT BOTM WINNER
You aren't disappointing me, Eric. Looks great.


3DogNate

"You Meet the Nicest People on a Honda"
Looking very good. If the rest turns out like that and the engine you'll have one heck of a good looking Honda added to the herd.


trek97

No Custom Title
DTT BOTM WINNER
Thanks guys,
and Thank goodness I had Sparckmoto send my custom harness UN-wrapped.
I miscommunicated one of my needs and flat out forgot HALF of my needs. haha.
But, it all worked out super. Thanks Matt.
also, Thanks for the sockets Corey!!!











Picked up an NOS sealed beam along w a cheap H4...



Cut w Dremel, JB Weld to seal and a pair of pop rivets to keep it all together.



Picked up a clean pair of NOS rings from cmsnl.com



Viola...Factory LED w all the factory mounting hardware and adjustment.





trek97

No Custom Title
DTT BOTM WINNER
Thanks fellas.
Following Irks lead on a brake upgrade.

Barely adequate, horribly Squeaky, Crazy heavy - Factory Brake Set up...




I'd like to add a dual piston - Suzuki, SV650 Tokico...



Along w a Kawasaki Ninja rotor.



Starting w a paper template and best guess. haha



Hand filing to ensure both mounts are parallel AND square w the rotor.
Ugh this was the worst part of the whole mod.








3 pieces total, top plate is 1/4" and two bottom are 3/8" thick aluminum.



Center plate will transfer all braking force to the fork lower.
The two 8mm bracket bolts won't see any force.
Other than holding the thing on.




Fresh kit going in...




This 10 pic max sucks. To be continued...haha

Last edited:

trek97

No Custom Title
DTT BOTM WINNER
Ok continuing on from last post...Ugh. Part two - Brake upgrade.



I made a video showing the pads on the rotor, but know I can't seem to find it...weird.
They look to have a nice, straight contact on the rotor.
I guess you just have to trust me, I like to keep my skin on my body. haha.

Copper sulfate solution warming in the ultrasonic on the patio.
Doing a fancy Irk Miller etch, to dress it up a bit.




Folk artsy, Grape vines to keep w her name..."Belladonna Verdicchio"



22 minutes in the bath gave it a nice deep etch.
I may cut some details into the leaves later.




Weight comparison to stock...in grams, sorry.









The new brake comes in at 1.75 pounds lighter than the factory. WOOHOO!



Fitted and waiting for banjo fittings and new bolts to finish...

Last edited:
