Bultaco Bandit El Montadero 360

[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

3000 and 5000 grit 3" Trizact Foam Disc...ADD/OCD go together

Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

We would have world peace if more people were like my wife

Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

https://vimeo.com/139792746trizact 3000 and 5000 the short version for the don't bore me get to it crowd


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Colors sanding using a Harbor Freight mini 3" d/a and a Harbor Freight 6" d/a polisher. 3M Trizact 5000 grit foam discs.

I have a confession. This build we have been trying to use as many air tools as possible to cut my the build time down. Used the Dynafile on the frame and sprayed it.

All the prep work for the tank and cowl were done with the 3" d/a. The hand color wet sanding was done with 600, 1000, and 2000 but that will be replaced with the small d/a next time.

The aluminum cases were sanded with the 3" d/a and then bench polished.

https://youtu.be/GfO7xJeIlhI


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Sent from my iPhone using Tapatalk



[Quixotay]

Re: The Count Mount Zeke's El Montadero 360

"Zooid" is going to be an nice addition to the room... and.... if you want to keep using the wife's table for your build(s).. suggest you add her bike to the pics "wink"

Cheers



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

"Zooid" is going to be an nice addition to the room... and.... if you want to keep using the wife's table for your build(s).. suggest you add her bike to the pics "wink"

Cheers

my Wife is very happy that Zoöid won't be around too much longer (about a year) and then we will be handing it over to Fuller next year at Barber.


Sent from my iPad using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

I have a question. How much time did y'all spend aligning the forks every time you took a spill?


Took me two hours to align the front end. Bultaco's front end tolerance on the triples seems a little loose.

There is a definite sequence for aligning the front end of a Bultaco.
1: Jacked up the front end after assembled.
2. Removed the stanchion plugs..
3. Loosened all bolts.
4. Rotated the fork tubes to find least amount of stiction inserted and into top triple.
5. Aligned like a bicycle.
6. Tightened lowered triple bolts.
7. Tightened the lower fork tube pinch bolt on the left side.
8. Tightened the axel nut.
9. Tightened the right lower pinch bolt.
10. Tightened the stanchion plugs.

Needs a for brace.


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Don't let the caswell cure in the petcock threads!

We used an old petcock and heated the end up to loosen the epoxy.

Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Braaap Taco Timehttps://vimeo.com/140576191


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

First ride! Who knew Bultaco had a reverse?https://vimeo.com/140587842 guess my timing is off? lol


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

So I had a triumph shirt on and the bike didn't like it! Changed shirts now it is turning the right direction!https://vimeo.com/140599113


Sent from my iPhone using Tapatalk



[Quixotay]

Re: The Count Mount Zeke's El Montadero 360

ocatluB, ocatluB, ocatluB



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

I am still scratching my head how in the heck did my timing end up firing at TDC.

So I put the verneer gauge in and checked my timing. The points were breaking at TDC...well they needed to be breaking at 3.30-3.50 mm BTDC for the Bandido and 3.00-3.10 for the Montadero. It looks like my woodruff key maybe suspect??? For on closer inspection it looks non existent.

Now the newer electronic ignition Bultaco's had an electronic ignition but this has a magneto. According to the instruction it requires Bultaco's 110v timing light. Which I don't have.

So I reset the timing using the been we gage and yes I had to turn the points plate almost to the other stops clockwise from where it was set. So if it was the woodruff key why...I am still scratching my head. Unless I set it ATDC because I was thinking it rotated clockwise instead of counterclockwise?


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

Talked with Lynn Mobley and he said with a half kick it can recoil and run backwards.


Sent from my iPhone using Tapatalk



[ABCanuck]

Re: The Count Mount Zeke's El Montadero 360

That might possibly be the coolest trick ever


Sent from my iPhone using Tapatalk



[johnu]

Re: The Count Mount Zeke's El Montadero 360

Talked with Lynn Mobley and he said with a half kick it can recoil and run backwards.


Sent from my iPhone using Tapatalk

That is exactly what would have happened. Seen it several times before.



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

That might possibly be the coolest trick ever


Sent from my iPhone using Tapatalk

just think Zeke and I didn't know a two-stroke from a four stroke three years ago and now we can make a 2 stroke go backwards!


Sent from my iPhone using Tapatalk



[Texasstar]

Re: The Count Mount Zeke's El Montadero 360

That is exactly what would have happened. Seen it several times before.

johnu you are so right! My friend Tom Laird said he was doing a TT on his Sherpa and it backfired got his attention in a hurry when it came back at him!


Sent from my iPhone using Tapatalk
