Post a pic of your motorcycle as it sits

teazer said:
I need to finish painting the bodywork and get this thing down the strip. Just picked up a small Bosch water pump, so now I can fit the lock up clutch and Banshee clutch cover. After I get a few parts machined that is....

Wow. Can we see more?

Thanks.

Starting at the front end, the caliper is an alloy Economy Cycles replica with aluminum pistons. Disk is a drag race unit retained with Titanium bolts.

Forks are RD350, suitably shortened. Stem was pressed out and replaced with a modified aluminum GSXR stem

Motor is RD350 bottom end with RD400 transmission, Banshee clutch, TZ crank and TZ750 (700 type) top end with Blaster reed cages and 34mm carbs. Ignition is Motoplat self generating. clutch cover is modified R5 to take a TZ water pump.

Radiator is some small dirt bike - don't remember which - on custom mounts

Tank is 1 gallon aluminum hiding under a carbon fiber tank cover with integral side covers. That I molded around a set of RD400 side covers and a narrowed RD400 US style tank.

Swingarm is longer than stock and takes the wheelie bar. Shifting is by CO2 cylinder through pressure regulator and solenoid triggered off a button on the left bar. Power to that solenoid and shift light come from a 4 cell RC radio graphene battery.

Tires are slicks, rims are aluminum, Seat is also aluminum.

I got the pipes as rolled cones (unwelded) so I had to weld the cones and then work out the shapes, cut and welded them to fit in nice and tight.

Much of the rear frame and some of the top tubes were replaced with Chrome moly thin wall tube, but same basic shape as stock without some of the more complex curves.

Nothing mind boggling difficult so far. If the chassis works, I'd like to build a long stroke motor ie a 400 or maybe with a 10mm banshee crank but ports become an issue and it's cheaper and easier to go straight to a CPI banshee and skip to 120 plus HP.


Attachments

  • DSCN1655.JPG
    2.9 MB · Views: 204
Tank:

Welding aluminum was fun, but the next one will look much better....


Attachments

  • DSCN2555.JPG
    3.2 MB · Views: 204
The "tw200" as of this afternoon.


Sent from my SM-G920V using Tapatalk

The 80 XS is starting to look different. 2" lowered forks, superbike bars, a K&S left switch, and no wiring. Still have a ways to go, but it's progressing quickly


Attachments

  • 20190615_164039_HDR.jpg
    1.9 MB · Views: 203
Ducati F1 race replica is moving along slowly. Received a title last week along with frame stamps so I can number and title my new frame. Wheels painted, bodywork painted, front end built, aluminium swing arm purchased, front discs acquired,brake adapters bought, put the four pot Brembos that I got years ago on the front end, and a lot of smaller items made or bought. Now is time for the real work to start......


Attachments

  • Ducati 800SS for Montjuich project.jpg
    Ducati 800SS for Montjuich project.jpg
    167 KB · Views: 205
  • F1 parts ii.jpg
    F1 parts ii.jpg
    187.4 KB · Views: 211
  • K1100 Marzocchi forks four piston brembos paso triple tree.jpg
    K1100 Marzocchi forks four piston brembos paso triple tree.jpg
    208.5 KB · Views: 208
  • Paso Wheel 2.jpg
    Paso Wheel 2.jpg
    221 KB · Views: 198
  • PASO WHEEL.jpg
    PASO WHEEL.jpg
    141.1 KB · Views: 197
My projects have been dormant for quite a while now, but I swear I'll get to them... someday...


Attachments

  • Projects.jpg
    101.5 KB · Views: 469
Just about to drag this one out of mothballs [5 years ! ::)], put on hold and with thoughts of selling when my health was at it's lowest. :'(

Healthy again and in almost full remission from the kidney issue that laid me low - time to get on.

It's still in Streetfighter guise, but I have all the parts to switch over to Cafe Racer .................................. 8)

Even started a build thread to keep me enthused.


Attachments

  • S ON AVON 003.jpg
    S ON AVON 003.jpg
    83.8 KB · Views: 378
  • S ON AVON 005.jpg
    S ON AVON 005.jpg
    92 KB · Views: 406
  • S ON AVON 012.jpg
    S ON AVON 012.jpg
    2.1 MB · Views: 168
Since quitting work I can finally get all my bikes running again.So far, I have these three on the road again. Just have to get the carbs right on the yellow one, then my Paso is next........


Attachments

  • 99' 900SS.jpg
    99' 900SS.jpg
    81.1 KB · Views: 374
  • Duc 851 on Patio.jpg
    Duc 851 on Patio.jpg
    248.4 KB · Views: 181
  • Crackhead Duc V.jpg
    Crackhead Duc V.jpg
    83.5 KB · Views: 185
dewjantim said:
Since quitting work I can finally get all my bikes running again.So far, I have these three on the road again. Just have to get the carbs right on the yellow one, then my Paso is next........

That is a beautiful yellow SS.
